Each of the models below is available as a high-quality, laser-cut acrylic model in either kit or fully assembled form. All models come attractively packaged with everything needed to finish the model (even a screwdriver). No special model-assembly skills are needed: the models just screw together in typically 15-20 minutes.

Rack-and-Pinion Steering

Rack-and-Pinion Steering

from 35.99

This model demonstrates, with transparent acrylic parts, how a typical rack-and-pinion steering mechanism works. The steering wheel is connected to a small round pinion gear, which engages with a long, straight rack gear (hence the name rack-and-pinion). When the pinion gear turns, the rack gear slides back and forth, which in turns pivots a pair of steering arms, one on each side.

This core of this model is included in the Radial Engine Car model.
